CPU |
- 9th/8th gen Intel® Core™ i7/i5 processor (Coffee Lake) with TDP 45W
|
Chipset |
|
System Memory |
- 2 x 260-pin DDR4-2666 non-ECC SO-DIMM, up to 64GB
|
Graphics |
|
BIOS |
|
COM |
- 2 x RS-232/422/485 with isolation supported
|
USB |
|
Ethernet |
- 2 x 10/100/1000 Mbps Ethernet (Intel® I210-IT & Intel® I219-LM, AMT supported)
|
Display |
- 1 x HDMI 1.4
- 2 x DisplayPort 1.2
|
Storage |
- 1 x 2.5" SATAIII SSD/HDD
- 1 x M.2 Key M 2280 NVMe SSD slot
|
Audio |
|
Expansion |
- 1 x Full-size PCI Express Mini Card slot (USB + PCIe signal)
- 1 x Half size PCI Express x16 Gen3 slot
|
Others |
- 1 x Power on/off button
- 1 x DC power input connector
- 2 x SMA-type antenna connector
|
TPM |
|
Power Supply |
|
Watchdog Timer |
- 65535 levels, 1 to 65535 sec.
|
Operating Temperature |
- 0°C to 40°C (32°F to 104°F)
|
Relative Humidity |
- 10% - 90%, non-condensing
|
Vibration Endurance |
- 3Grms STD, random, 5 to 500 Hz, 1 hr/axis
|
Dimensions (W x D x H) |
- 250 x 240 x 90 mm (9.8" x 9.44" x 3.54")
|
Weight (net/gross) |
|
EOS Support |
|
Certifications |
- CE, FCC Part 18
- EN 60601-1:2006 + A1:2013 + A12: 2014
- BS EN 60601-1:2006 + A1:2013 + A12:2014
- EN 60601-1-2:2015 + A1:2021
- BS EN 60601-1-2:2015 + A1:2021
- ISO 14971:2019
|
